Category Archives: Post and Beam

Dismantling the Pawlet Corn Crib (and Looking for an Owner!)

Featured

Posted on by
Reply

As spring makes its arrival here in Vermont, we have taken the opportunity with the warmer days to dismantle a small timber frame barn near our shop.

IMG_0576

This frame measures 14×17 feet.

The frame is part of a hillside farm that was settled in the late 1700s. This barn had a combination of hand forged and cut nails in siding and roof boards, and we believe it dates to the 1820s or earlier.

Pawlet corn crib

The frame has been sinking into the ground because there was no real foundation. We caught it just in time!

This barn was used for storage of both corn on the cob and oats. The interior of the barn was partitioned off on one side so that oats could be stored in tall wooden bins.

We absolutely love the homemade sliding doors at the bottom of the bins that allow for the oats to pour out. Imagine our surprise when we lifted the door and found that oats remained inside! Of course, we had to keep some of these vintage oats for our collection, as well as some of the old corn cobs that we found. We hope that whoever purchases this barn will be interested in the artifacts and history of the space. No wonder storage space in the shop is always tight!

We started our dismantling by stripping the slate off the roof. We then labeled and removed the roof boards.

In the next photo, you can see the slotted vertical siding boards. This was a typical method of siding for corn barns because it allows air flow through the building that will dry out the corn. What is unusual in this case is that the slotted siding was installed from inside, and then two large swinging doors were installed on the outside. After much head scratching, we concluded that this unusual method allowed for the doors to be closed in inclement weather to keep out the Vermont storms. The doors must have been strategically opened during good drying weather after harvest.

IMG_1094

This adorable frame has a petite ridge beam and half-round rafters.

The surrounding mountains at this hillside farm are stunning.

IMG_1065

On a beautiful sunny spring day, we popped the pins out of the frame and were ready for disassembly.

IMG_1053

IMG_1055

The frame is made from beech and pine trees. The color on these posts is stunning.

Once the frame was down, we pulled all of the nails and shipped the beams and boards back to our shop for restoration.

IMG_1070

We like frames that are manageable to disassemble and move by hand!

Our next steps on this frame will be to power wash the beams and boards and then make repairs to the bottoms of the posts where they fatigued over the last two hundred years. For the post bottom repairs, we will use similar hand hewn inventory and an English scarf joint to make a strong and beautiful repair.

This frame would make an incredible little cabin, mudroom addition on a house, or it could become a small barn once again to house chickens, goats, or sheep. Who knows, it may even house oats and corn once again.

Interested in learning more?

See drawings and learn more about this vintage timber frame or Contact Me.

Advertisements

Link

Last spring, we tipped up a new timber frame barn here in Vermont. We had first begun discussing the barn with the family over a year previously, and worked closely with them on the design for a 28-by-40 foot barn.

We shaped the timbers over the course of the winter, and it was ready for the arrival of spring… as were we! The owners will be using the new post and beam barn as a seasonal living space and as a place to indulge in their wine-making hobby. The project and our clients were a delight, and we want to share the story of this frame.

Timber frame barn in vineyard green mountain timber frames

During the design phase of the project, we decided with our clients to use local hemlock timbers, and settled on 10-by-10 inches as the size for all the posts, girts, and top plates. The timbers were sawn at a sawmill just five miles from the barn location.

Post joinery is cut for timber frame

We decided to construct this frame using a principal rafter and purlin system. This means that each 28-foot bent section has massive rafters which support horizontal purlins. In this design, the roof boards are put on the frame running vertically.

Shaping swoops on heavy purlin timbers

Jesse shapes the “swoops” on the ends of the heavy purlin timbers.

Another exciting feature of the barn design was the inclusion of four dormers in the roof structure. The barn will have a two-thirds loft where the dormer interior can be enjoyed up close, and the dormers in the cathedral space will provide natural light and aesthetic balance for the exterior.

One of the beautiful things about timber frame construction is that we can craft each joint and wooden connection “on the ground.” That way, on raising day, each labeled joint slides together and receives the oak pegs. Since we wanted to go through this preparation process on the dormers as well as with the larger sections of the barn, we assembled each side of the roof system flat on saw horses and got to work.

40 foot long roof system_Green Mountain Timber frames

This roof section is 40-feet long, and laying it out flat on the ground allowed us to check all the joinery and test-fit the dormers

We wanted to use a traditional ridge beam for the dormers. Because the pitch of the roof was 11 inches of rise for every 12 inches of run, the ridge beam had to be shaped to match the roof pitch rather than remaining at square, 90-degree angles. This made laying out and cutting the compound angles challenging. I remembered my grandfather’s old-fashioned miter box that he used when I spent time in his shop as a kid. We replicated my Papa’s angle box to cut our dormer ridge beam, and it worked great!

jig box for cutting ridge beam green mountain timber frames

We built a jig box to help us cut the complex angles on the dormer ridge beams.

dormer joinery on new timber frame roof

Matt inspects dormer joinery

We constructed and fit the four bents and assembled each of the 40-foot eve walls. We used math, geometry, and sharp tools to make certain that the frame would rise up straight and true on its foundation in the spring.

Timber frame bent assembled green mountain timber frames

Jesse enjoys the completion of a gable bent. There is an upper doorway framed in this gable that will lead from the loft out onto a small balcony.

Soon enough, spring arrived, and we were ready to put the frame up. Our client and his son helped us to whittle the proper points on the oak pegs. We use a “shaving horse” to shape the pegs. This ancient design works beautifully to hold the peg hands-free while a draw knife or spokeshave is used. Footwork operates the clamping mechanism.

shaping oak pegs green mountain timber frames

Our shaving horse works great for shaping pegs!

Next, we began assembling bents and driving the pegs to hold them fast.

Pegs are driven into a bent before it is tipped up

Pegs are driven into a bent before it is tipped up

Before we knew it, we were tipping up the final bent.

lifting final bent into timber frame baren

We absolutely love the way the four post bent design draws the eye down the center of the building and gives the whole thing a cathedral feel.

timber frame erected and pegged in Vermont

The lower cube of the frame is erected and pegged.

The next step was to install the top plates, which tie the bents together and support the weight of the rafter system.

green mountain timber frames new construction

Next, the principal rafters went up. As we set each pair, we fed the tenoned purlins into place, as well as the braces that we placed in the rafter system in order to make it ridged.

eve purlin placed in roof and dormers installed

We set an eve purlin into place

It was great fun to assemble the dormers – this time standing upright on the roof system instead of sitting flat on saw horses at the shop. We set the little ridge beams, rafters, and dormer posts. The pegs went in, and we were delighted with the result.

dormers and pitch on timber frame roof

The dormers are 5-feet wide, and the pitch is matched to the main roof.

Here is a crow’s eye view of the completed rafter system and the dormers:

purlin extensions and steel plates to create a generous roof overhang

We used purlin extensions and steel plates to create a generous roof overhang.

hemlock roof boards Green Mountain Timber Frames

The warm colors of the hemlock and roof boards are wonderful.

It was a great joy to collaborate with this family to create a structure in a beautiful setting that will be used and enjoyed for a very long time to come.

Here is hoping that many a glass of wine, crafted in this barn, gets raised by friends and family for generations! Cheers!

Do you dream of living, working or making wine in your own timber frame? At Green Mountain Timber Frames, we restore and build timber frame barns and homes, both new and old.

Give us a call.

completed dormer_Green mountain timber frames

I can imagine sitting in this dormer with a cup of coffee and enjoying the view for a very long time!

Camp Moonrise…Or How Our Old Barn Home on Lake Champlain Found Its Name

Featured

Posted on by
Reply

Steven KelloggToday’s guest post comes from the talented author and illustrator, Steven Kellogg. We so enjoyed working with him and are honored to have him write for our little blog!

I am an artist who, for decades, on rambles throughout the northeast, has admired old barns. Recently, I have been thrilled with the acquisition of a rugged, hand hewn barn frame The barn itself had been slowly deteriorating on the abandoned farm it had once served, and then was subsequently rescued, and restored.

4

The historic gunstock frame stood tall and true on the Champlain Island of North Hero

It came into my life because, with our family grown and my wife having developed some health issues that required a residence that is handicap accessible, I decided to build a home with supportive features to accommodate those needs on a piece of property on the shore of Lake Champlain that we had owned for a number of years.

I envisioned a house with several spacious, wheelchair accessible rooms overlooking the lake, that, most importantly, would have an old barn at its core. The interior would be designed so that classic proportions, a richly-toned original ceiling, and sculptural, hand hewn beams would serve as the major architectural themes.

Window View_Steven Kellogg Timber Frame Home

The windows look out over the beautiful lake, and towards the barn’s original location

My search for just the right barn led me to Dan McKeen of Green Mountain Timber Frames, and then to his friend and colleague, Luke Larson, a master carpenter in Middletown Springs, Vermont. They had a number of impressive barn frames available in their inventory. Each one had been rescued from its original location on the farm where it had originally served. Each of these restored barn frames was like a rural cathedral with beautiful, simple, architectural lines, massive, hard wood beams, and magnificent notched and pegged construction.

Amongst these treasures, one of them stood out because of its superior details and appropriate size. I could picture it perfectly on our property. This particular historic frame came with added appeal: it was originally built around 1780 on one of Lake Champlain’s North Hero Island farms, not far from its prospective new home on our wooded knoll overlooking that very same lake.

When Luke and his skilled crew erected the barn frame on our wooded site, it seemed so harmoniously situated that it gave the impression that it had always been there.

Because our land is on the New York side of the lake, we resolved to honor the Adirondack tradition of calling rustic lakeside and woodland homes “camps” and giving them names. Prompted by the fact that the reconstructed North Hero Island barn faced our favorite monthly spectacle — the full moon lifting above the Vermont mountains and the lake — we decided it would henceforth be known as “Camp Moonrise.”

Interior View_ Steven Kellogg Timber Frame Home

The sign over the hearth reads “Camp Moonrise”

Now that we are happily putting down roots in this beautiful building and enjoying every hour of living here, we will be forever grateful to Luke, Dan, and their team of master craftsmen for their passion for old barns and their creative talents, which made this opportunity available to us.

Read more about the process of restoring this old barn in this blog.  For the Camp Moonrise project, Green Mountain Timber Frames partnered with the talented staff at Cloudspitter Carpentry and Hall Design Group.

More Images of the Beautifully Restored Barn Home – Camp Moonrise

This slideshow requires JavaScript.

Sill and Post Repairs…Plus More Split Rail Fence!

Featured

Posted on by
Reply
Reading this in your email? For easier reading – Click here.

We recently finished the first phase of a barn repair project in Springfield, Vermont, stabilizing a gorgeous little barn from the early 1800s.

1_Barn Repair_Green Mountain Timber Frames

History of this Historic Timber Frame

The vintage timber frame is part of the historic Kirk homestead. We believe it was William Kirk Junior who built this barn. The son of a revolutionary war soldier from Springfield, William purchased the farm in 1809, and most likely built this structure at that time.

In 1834, the land records note that William Kirk mortgaged the farm to a Mr. White for $300. It may have been a tough year for farming, or perhaps William needed cash to work on the second barn on the property, which is attached to the older frame.



2_Large Vermont Barn_Green Mountain Timber Frames

The large barn is connected at a perpendicular angle to the smaller old structure. Farmers often sought to create a protected barnyard area for livestock and equipment, and the “L” profile of the attached barns does just that.

The records state that the loan was to be paid back annually over three years in “good salable neat stock or grain.” William must have successfully paid off the mortgage, as the property stayed in the family for a total of 97 years before being sold.



In 1864, William sold the farm to his son Aaron. Thirty years later, Aaron conveyed the farm to his younger brother Reuben, a Civil War veteran who had fought in the 10’th Regiment, Vermont Volunteer Company. The property stayed in the family until 1905. Many thanks to the current owners for sharing their careful historical research with us!

A Barn in Need of Repair

While the barn had beautiful stone foundation work, the water had pushed and the frost heaved against the stone and sills, and the joinery of the structure was deeply strained. The stone wall under the gable was collapsing, and four different posts had “torn their trunnels” and dropped down out of the upper beams.



3_Corner Post Beam_Green Mountain Timber Frames Vermont

This corner post dropped as the sill beneath it deteriorated, and the pegs broke allowing the tenon to drop out of the mortise.



Our Approach to Restoration

Our project was to jack the posts back home again, and to replace the sills. The barn was listing dangerously towards an eve because braces had failed. We used a series of come alongs as we lifted posts in order to coax the wall back towards plumb.



4_5 sided ridge beam_green mountain timber frames

Note the beautiful five-sided ridge beam! Many of the braces had failed, and in this photo we are coaxing towards the western horizon. On the far wall, you can see where one of the posts has dropped.

As we lifted, we were able to feed the tenons home.





5_tenon to horizontal timber_green mountain timber frames

We were able to bring this tenon right back into the horizontal timber. Even the siding boards slid back into the grooved channel in the beam where they started out.





7_lifting historic barn in vermont_Green Mountain Timber Frames

Here we are lifting the corner of the building in preparation for new pressure treated sills



The Split Rail Fence

But wait- what about the split rail fence? After posting our last blog about the fencing used as collar ties in Tunbridge, we were surprised and delighted to discover split rail fence pieces used as floor joists in the newer and larger of the Kirk barns!



8_Vintage floor joist_Green Mountain Timber Frames

Old William Kirk was a resourceful fellow. Most likely the original floor joist snapped, and so a nearby rail was conscripted for the purpose.



A Barn Rebuilt to Last!

Now that the frame has repaired sills and is stabilized, the terrific crew at Terrigenous Landscape Architecture will re-build the dry laid stone foundation and wall on the gable end. Scott and his team have already installed a drainage system around the exterior of the barns, which will protect the repaired barn complex and stonework from future freeze and thaw cycles.

We look forward to returning to Springfield in the fall after the stone work is accomplished, to continue frame and siding repairs. In the meantime- happy fencing to all you farmers out there!

Do you have a vintage barn in need of repair? Dream of living in a historic barn home?

Contact us!
Luke@GreenMountainTimberFrames.com



“Did a Farmer Build This Barn?”

Featured

Posted on by
Reply
Reading this in your email? For easier reading – Click here.

Since we inspect dozens of barns every year, and because we’ve got lots of barns for sale, we often receive this question. In the 18th century, who, exactly, was it that was crafting these beautiful structures that required such skill and attention to geometry, math, fine woodworking skills, and practicality?1790-barn-with-5-sided-ridge-beam

At times, we have heard the question asked in a mildly derisive manner, as if it was built by farmers rather than carpenters. At other times, we are asked in a tone of reverence for the broad spectrum of skills required and the appreciation of raw materials, motivation, communal commitment, and just plain hard work involved. It is in the latter spectrum that we solidly fall in our assessment of our New England structures and their creators from so long ago.

Our Latest Vermont Timber Frame Project

This week we spent two intense days disassembling a beautiful addition on a house in Tunbridge and Chelsea, Vermont. Two towns, you may be asking? Yes indeed-the town line ran right through the center of the property, and the house is in Tunbridge, while the addition was in Chelsea. While mid-stream on the addition dis-assembly, a town truck from Tunbridge came by, and the driver stopped. Leaning far out the window of the dump truck, he called to us, “What, moving out of Chelsea, eh?”

The joke was followed by much guffawing and laughter. I am not sure why that dump truck had been driven to the literal dead end of the road, but I am suspicious it may have been for the purpose of telling that joke- and I love it! News of renovations and changes travel fast in our small Vermont towns.

timber frame addition in the snow green mountain timber frames

The first time I looked at the addition, the snow banks were deep.

Early gunstock timber frame green mountain timber frames

What a difference a couple of months can make in Vermont! The house is a beautiful 1820s gunstock frame.

Let’s get back to the theme of “farmer built.” As someone raised on a Vermont dairy farm, and accustomed to the great joys and hardships of farming, I can not state strongly enough my appreciation for the barns and their builders of yesteryear. We at Green Mountain Timber Frames are so fortunate to get the insider’s view of many local barns, and we have been able to trace the progression of a master timber framer through our valleys by observing unique “signature” qualities of frames.

Recently, we noted a very unique rafter birds mouth detail for example that we have seen in only two local structures- which “happened” to be only 20 miles apart. Was this a case of farmers sharing ideas and techniques with their neighbors, or is it because a master builder traveled around the area coaching and aiding as farm families built their barns?

Hand hewn rafters green mountain timber frames

The rafters are beautiful petite spruce with a half-lap joint at the peak.

In the case of this structure in Chelsea/Tunbridge, we found an extra special clue that the addition was indeed farmer built. They used pieces from a split rail fence as collar ties to support the rafters!

split rail collar tie green mountain timber frames

I would love to have heard the conversation where they decided to grab some rails from the nearest fence! With the property being high on a mountain, it would have been a long trip to a saw mill, and the split fencing was right there. “Keep the job moving!” we builders like to say.

collar tie and hand made nails green mountain timber frames

Note the beautiful hand-made nails that hold the collar tie in place. The family for whom the country road is named were blacksmiths as well as farmers, and I am certain they made these nails themselves.

The posts of the addition had been devastated by carpenter ants, and the foundation was crumbling. Because of this, we will not be restoring the frame. Rather, we will use the hemlock roof boards and the beautiful rafters on the future restoration of another building.

vintage hemlock roof boards green mountain timber frames

The roof boards have beautiful color that only time can create.

We are grateful to the property owner for his desire to see the materials recycled. Just like the farmer who originally put this structure together, we want to recycle all that we can. In fact, we left those vintage pieces of split rail fence behind with the property owner, and I expect they may be put right back into the fence that is only thirty yards from the house to “live another day” back where they came from.

Are you looking for historic barns for sale? Want a new-old barn home?
We’d love to help!

Luke@GreenMountainTimberFrames.com or (802) 774-8972



The 1840s Historic Home: Saving Precious Timbers

Posted on by
Reply
Reading this in your email? For easier reading – Click here.
We recently finished working on a small project dismantling part of an 1840s home. The residents were tearing down a section of their historic home to make room for a new addition.
historic home renovation_Green Mountain Timber Frames

The new addition honors the style of the original, and retains the stone foundation

Honoring the value of the vintage wood, they asked Green Mountain Timber Frames to help them salvage parts of the structure.
The answer? Of course!
While the frame itself was beyond repair, with careful disassembly of the timbers, we were able to save the vintage flooring, siding boards, and many of the hand hewn beams. The owners were very happy to know the materials are being recycled and some of the wood was even put to use in their new addition.
historic barn frame 1840 post and beam _Green mountain timber frames

The original wall sheathing is 1/2 inch boards

We look forward to working with these materials in future restoration projects. The beams, flooring, and siding will help us maintain the authentic, historic look and we are grateful to the owners for sharing them with us.
Post and beam addition_Green Mountain Timber Frames

The hand hewn beam shown at the top of the wall is 30 feet long

They even wrote us a lovely note and while we risk sounding immodest, it made us so happy that we wanted to post it here. We are so glad the owners share our love of history and facilitated our collaboration to recycle the beams!
“Thank you so much for the caring removal of 1840s ell on our home. We are still so amazed that the work was done so quickly!  Thank you for sharing information on the way our post and beam addition had been constructed.  Our shadow box of various pieces of the ell will have a place of honor in the new addition, too.”
When springs finally comes to Vermont this year, we will be dismantling another historic building on their property to salvage the materials.

Do you have a historic property that you want to preserve?

We would love to help.

802.774.8972

Restoration of an 1806 Barn

Posted on by
Reply
Reading this in your email? For easier reading – Click here.

Here at Green Mountain Timber Frames, we are delighted to have a new member on our framing crew! Matt Peschl is not a new face or a new friend, as he worked with us for key projects over the past 12 years. But now, Matt has officially joined us on a full-time basis and we could not be happier about it!

matt-peschl_green-mountain-timber-frames



Reminiscing About a 2011 Barn Restoration

Luke and Matt worked together on a project in 2011 and we’d like to take this opportunity to share it with you. The repairs were done on a small barn on a beautiful property here in our hometown of Middletown Springs, Vermont. The homestead dates from before 1800 and we believe the barn that we worked on was built in 1806.

img_4636
We repaired the red barn, which sits nestled under the mountain among a collection of vintage barns and corn cribs

The barn had two main structural issues: rotten sills and a rotten upper beam called a top plate that supports the rafter bottoms. We decided to start from the ground up.

repairing-rotten-barn-antique-sill-green-mountain-timber-frames

The sills were tired from sitting directly on stone for 205 years

We began by using hydraulic jacks to strategically lift the barn up off of the stone foundation. This allowed us access to the sills where they needed work. In our restorations, we use vintage materials for replacement parts whenever possible.

The next photo shows Luke using a chain mortiser to begin cutting to splice in a new piece.

repairing-sill-of-antique-barn-green-mountain-timber-frames

The beginnings of a scarf joint

With the weight of the barn held up on jacks, we were able to cut joinery on a new sill piece and fit it together with the still sound original section of sill.

repaired-sill-in-old-barn-green-mountain-timber-frames

Here we have used an English scarf joint to add in a new section of sill

One eve wall of the barn was close to grade and the sill was entirely rotten. For this wall, we chose to use Locust wood for the sill replacement.

Locust grows locally and is a remarkable species. As a kid growing up on a Vermont farm, I had the opportunity to work with locust for a long time- at times more cheerfully than others! My father, siblings and I cut many locust fence posts from the woods. We would drive the locust directly into the ground and, because of the nature of the wood, it would last many years even when underground.

In fact, I have stumbled across old, grayed locust fence posts deep in Vermont woods. The old fence posts tell the story of much of Vermont’s land being cleared of forest during the 1800s. Now, the forest land is expanding to take up a larger portion of the state. Locust posts, as well as stone walls, stand sentry in parts of our current woodland to tell the tale and transitions of our farming history.

locust-replacement-sill-antique-barn-green-mountain-timber-frames

We copied the joinery from the original sills before installing the new timber

Once we had the barn set back down on repaired sills and had rebuilt the stone foundation, we took a look at the second major issue. What we found was some serious rot caused by a leaky roof at some point in the past. The first roof had been cedar shakes, later replaced by slate.

rotten-beam-in-antique-barn-green-mountain-timber-frames

Folks, we have an issue!

In order to repair the top plate, we first set up a system to jack up and hold the rafters in order to free up space for our repair.

repairing-antique-barn-top-plate-green-mountain-timber-frames

The rafters are supported and we have cut out the rotten section of beam

We used an English scarf joint to make the top plate repair. When we need to replace a section in a barn, we use vintage materials from our inventory in order to get a matching color, tone and hue.

scarf-joint-repair-in-antique-barn-green-mountain-timber-frames

The top plate is repaired and ready to support the roof for another 200 years

Next, we replaced the siding windows and trim on the barn.

rebfurbished-barn-green-mountain-timber-frames

It is a great joy to have Matt on the team again. He joins us with a great amount of experience, both in timber framing and in every phase of construction. Most importantly, we really enjoy his company!

Do you have a vintage barn of your own that needs repairs?
Give us a call at (802) 774-8972.

Want to read about another timber frame project? How about the time we built a timber frame gazebo!
